GECOMINDIA is an ISO 9001:2000 certified critical care equipment manufacturing company. We manufacture world class medical equipment products which are being used in various hospitals and medical institutions throughout India and other Countries as well. Presently, we export to 15+ countries and we are the market leaders in Syringe and Infusion pumps in India with two factories, one in Tiruchirapalli and one in Chennai. Our organization comprises of engineers who have experience in various engineering & medical fields. Our organization was laid with a foundation such that we consistently exceed the customer experience. Read More
GECOMINDIA is an ISO 9001:2000 certified critical care equipment manufacturing company. We manufacture world class medical equipment products which are being used in various hospitals and medical institutions throughout India and other Countries as well. Presently, we export to 15+ countries and we are the market leaders in Syringe and Infusion pumps in India with two factories, one in Tiruchirapalli and one in Chennai. Our organization comprises of engineers who have experience in various engineering & medical fields. Our organization was laid with a foundation such that we consistently exceed the customer experience.
(Rs.)
GECOMINDIA (Rs.Not Listed)
Automatic detection of syringe type.
Standby Function.
Last infusion memorized (more memory - optional)
8+ hours battery backup when fully charged.
Compatible syringes : 5 / 6m1 (optional), 10 / 12m1, 20 / 30m1, 50 / 60m1.
Bolus Rate: User selective with anti-bolus drive 8. Time is auto-calculative proportionate to bolus rate 8 duration of bolus function used.
KVO : Kvo - 0.1 to 3 ml user selective & 1ml/hr or set delivery rate, lower of either.
Online change of rate with automatic time reset in accordance woth remaining volumne.
3 Modes of operations (Upgradeable / Lockable):
Rate Mode: Rate calculated automatically (with increment of 0.1m1)
TECHNICAL SPECIFICATIONS
110mm LED / LCD colored display for distant view
Dimensions: 230mm (L), 110mm (H), 150mm (D)
Weight: 2kg without I.V. pole clamp
Power supply: 180 — 240V 50 / 60 Hz
Battery: 11.1v DC LI-10N 2200 mAh, charging only when equipment is switched ON.
DOSAGE / PURGE BOLUS CAPACITY
50 / 60m1 syringe: From 0.1m1 to 1800m1/hr
20 / 30m1 syringe: From 0.1m1 to 800m1/hr
10 / 12m1 syringe: From 0.1m1 to 400m1/hr
5 / 6m1 syringe: From 0.1m1 to 200m1/hr (5m1 syringe usages A optional)
Increment of 0.1m1/hr for all syringe capacity.
User can't set target volume more than the capacity of syringe type.
DRUG DOSE 1 PATIENT WEIGHT CAPACITY
Patient weight from 0.1kg to 99.9kgs with 0.1 kg increment (more capacity optional). Solution volume: From 0.1 to 999.9
Drug mass: From 0.01 to 999.9mg with 0.1 mg increment.
Dose: From 0.01 to 99.99ug/kg/min with 0.01 increment.
From 0.01 A 99.99mm/kg/hr with 0.01 increment.
PRESSURE SENSING
Occlusion: occlusion is managed in 3 stages.
Low (300mm/hg), Medium (500mm/hg), High (900mm/hg)
ALARMS
Syringe disengagement, Occlusion, Near empty, Empty, KVO, Low battery, Technical error. (All the above errors are indicated / expressed on screen in words, audio beep & visual red light)
Equipment status during infusion: Green LEDs (3) move & infusion blinks on screen when equipment is infusion, KVO & Bolus LEDs glow when in use & continuous beep when KVO is achieved.
All alarms ore expressed through LEDs, sound 8 screen written words.
ACCURACY
Works on +/- 2%, accuracy with correct calibration & syringe variability.
CERTIFICATION / STANDARD
Our equipment is CE certified, IEC 60601-1, IEC 60601-1-2 & IEC 60601-2-24.
We are ISO 13485:2016 certified.
GECOM
We are a registered MSME company, financed under KV1C (Scheme of PMEGP)
"BEAS" syringe pumps are designed, developed 8 manufactured in Indio.
Due to continous developments specifications may vary time to time for advancement.
"BEAS" syringe pumps are developed with technical association with CIPET, Bhopal 8 Shidore Microsys, Pune.
